Digital Multimeter For Solar Power Systems & Power Equipment
KM-405 MK-II
General Specifications :
• Manual range
• True RMS measurement
• 250MΩ large resistance measurement
• 25000 counts high-precision display
• 100mF high capacitance measurment
• Auto power off
• Combined AC+DC voltage measurement
• NCV inductive electricity measurement function
• 20A current measurement
• Voltage / Resistance / Frequency / Diode / Duty Cycle / Temperature / Continuty
• Current input misoperation indication
• Flashlight
• Large screen with three displays (main display / auxiliary display / analog bar)
• Low resistance voltage measurement
• Maximum and minimum value
• Data Hold & Backlight
• Low battery indication
• Power Supply : 1.5V AA Battery × 3pcs
• Dimension : 180 × 90 × 50mm
• Weight : Approx. 384g (without battery)
